Meet the Standing Frames

Levacare / Levacare Pro

Standing devices are among the most important devices in rehabilitation and care. The stable design of the Levacare gives patients a firm, secure hold during their daily standing training. The standard version of the Levacare is supplied without a belt system, while the Pro version has an electric stand-up device.

Product Details

  • Table cut-out with ergonomic abdomen pad

  • Foot plate with heel cups and toe fixation

  • Lift support harness (size S, M or L)

  • Sturdy tubular steel construction in blue

  • Wooden elements made of multiplex with high-strength HPL coating

  • 4 double swivel castors with total locking

  • Integrated suction-blow control on the Levacare Pro

Technical Details

  • Total length: 118 cm

  • Total width: 77 cm

  • Tie bar height: 84 – 107 cm

  • Tie bar width: 48 cm

  • Table height: 100 – 130 cm

  • Table width: 66 cm

  • Table length: 59 cm

  • Max. patient weight: 120 kgMin./Max. patient height: 120 – 200 cm (smaller than 140 cm, a height-adjustable foot plate KR-724-X must be ordered)

Extra Equipment

  • Levacare (KR-100-B)without belt system

  • Levacare Pro (KR-111-B)with electric belt system

  • Lift Support harness "S" (KR-608-X)

  • Lift Support harness "M" (KR-607-X)

  • Lift Support harness "L" (KR-606-X)

  • Lift Support harness with rubber (KR-604-NO)

  • Lift Support harness with sitting assist

  • Lift Support harness with deeper seat support

  • Support bar with hip pads (KR-620-X)

  • Upper body support incl. headrest (KR-631-X)

  • Table top horizontally movable (KR-710-X)

  • Foot plate horizontally movable (KR-720-X)

  • Foot plate horizontally adjustable & height adjustable (KR-724-X)

  • Breast pad 15 cm (KR-744-X)

  • Breast pad 25 cm (KR-745-X)

  • Knee pads extra soft (KR-801-X)

  • Heel Velcro (KR-805-X)

  • Table edge beech, 4-piece (KR-602-X)

  • Foot plate elevation

  • Special colours available (RAL colour system)

Levatrain

The Levatrain standing device has an integrated electric belt system and makes it easier to stand up while providing a stable support. The trapezoidal base frame and the pivoting rear wheels also allow the standing device to be used by patients with wider wheelchairs

Product Details

  • Table cut-out with ergonomic abdomen pad

  • Foot plate with heel cups and toe fixation

  • Electric belt systemLift support harness (size S, M or L)

  • Sturdy tubular steel construction in blue

  • Widenable access area

  • Wooden elements made of multiplex with high-strength HPL coating

  • Pivoting rear wheels

  • 4 double swivel castors with total locking

Technical Details

Extra Equipment

  • Lift Support harness "S" (KR-608-X)

  • Lift Support harness "M" (KR-607-X)

  • Lift Support harness "L" (KR-606-X)

  • Lift Support harness with rubber (KR-604-NO)

  • Lift Support harness with sitting assist

  • Lift Support harness with deeper seat support

  • Support bar with hip pads (KR-620-X)

  • Upper body support incl. headrest (KR-631-X)

  • Table top horizontally movable (KR-710-X)

  • Breast pad 15 cm (KR-744-X)

  • Breast pad 25 cm (KR-745-X)

  • Knee pads extra soft (KR-801-X)

  • Heel Velcro (KR-805-X)

  • Battery box (KR-703-X)

  • Table edge beech, 4-piece (KR-602-X)

  • Foot plate elevation

  • Special colours available (RAL colour system)

  • Total length: 100 – 103 cm

  • Total width: 73 – 78 cm

  • Tie bar height: 80 – 100 cm

  • Tie bar width: 49 cm

  • Table height: 100 – 132 cm

  • Table width: 64 cm

  • Table length: 58 cm

  • Max. patient weight: 120 kg

  • Min./Max. patient height: 140 – 200 cm

Levatrain Max

The Levatrain Max was specially developed for plus size patients. The reinforced footplate and wider, highly stable frame for XL wheelchairs allow patients weighing up to 200 kg to stand firmly.

Product Details

  • Table cut-out with ergonomic abdomen pad

  • Parallel height adjustable handrails

  • Reinforced foot plate with heel cups and toe fixation

  • Electric belt system

  • Lift support harness (size S, M, L or XL

  • )Sturdy, extra wide tubular steel construction in anthracite grey

  • Particularly wide access area

  • Wooden elements made of multiplex with high-strength HPL coating

  • Pivoting rear wheels

  • 4 double swivel castors with total locking

  • The product images on this page show the standard version of the standing device. The final product changes optically due to optional equipment

Technical Details

  • Total length: 100 – 103 cm

  • Total width: 84 – 89 cm

  • Tie bar height: 80 – 89 cmTie bar width: 57 cm

  • Table height: 100 – 132 cm

  • Table width: 64 cm

  • Table length: 58 cm

  • Max. patient weight: 200 kg

  • Min./Max. patient height: 140 – 200 cm

Extra Equipment

  • Lift Support harness "S" (KR-608-X)

  • Lift Support harness "M" (KR-607-X)

  • Lift Support harness "L" (KR-606-X)

  • Lift Support harness with rubber (KR-604-NO)

  • Lift Support harness with sitting assist

  • Lift Support harness with deeper seat support

  • Lift Support harness with reinforced seat support up to 200 kg "XL" (KR-689-X)

  • Lift Support harness with reinforced seat support up to 200 kg "L" (KR-686-X)

  • Support bar with hip pads (KR-620-X)

  • Upper body support incl. headrest (KR-631-X)

  • Table top can be moved horizontally (KR-710-X)

  • Breast pad 15 cm (KR-744-X)

  • Breast pad 25 cm (KR-745-X)

  • Knee pads extra soft (KR-801-X)

  • Adjustable XL knee pads (KR-850-X)

  • Heel Velcro (KR-805-X)

  • Battery box (KR-703-X)

  • Table edge beech, 4-piece (KR-602-X)

  • Foot plate elevation

  • Special colours available (RAL colour system)

Levaflex

The Levaflex is the standing device with the highest functionality. The arm rails, knee support and footplate are tilted towards the patient before standing up or sitting down, making the process easier. The patient’s knees and behind are under less strain thanks to the tilt function, with the usual stability and safety

Product Details

  • Ergonomically adjustable knee guide

  • Table cut-out with ergonomic abdomen pad

  • Foot plate with heel cups and toe fixation

  • Electric belt system

  • Lift support harness (size S, M or L)

  • Sturdy tubular steel construction in blue

  • Wooden elements made of multiplex with high-strength HPL coating

  • Pivoting rear wheels

  • 4 double swivel castors with total locking

  • The product images on this page show the standard version of the standing device. The final product changes optically due to optional equipment

Technical Details

  • Total length: 100 – 103 cm

  • Total width: 73 – 78 cm

  • Tie bar height: 80 – 100 cm

  • Tie bar width: 49 cm

  • Table height: 100 – 132 cm

  • Table width: 64 cm

  • Table length: 58 cm

  • Max. patient weight: 120 kg

  • Min./Max. patient height: 140 – 200 cm

Extra Equipment

  • Levaflex (KR-214-B)frame colour blue

  • Lift Support harness with base (5 cm), size “S” (KR-608-X)

  • Lift Support harness with base (5 cm), size “M” (KR-607-X)

  • Lift Support harness with base (5 cm), size “L” (KR-606-X)

  • Lift Support harness with rubber (KR-604-NO)

  • Lift Support harness with sitting assist, sizes S – XL (KR-604-SH)

  • Support bar with hip supports (KR-620-X)

  • Upper body support with head and arm rest (KR-631-X)

  • Table top horizontally movable (KR-710-X)

  • Chest pad 15 cm (KR-744-X)

  • Chest pad 25 cm (KR-745-X)

  • Knee pads extra soft (KR-801-X)

  • Heel Velcro (KR-805-X)

  • Battery box (KR-703-X)

  • Table edge beech, 4-piece (KR-602-X)

  • Foot plate elevation

  • Special colours available (RAL colour system)

Car Brake

For A Full Range Of Accessories & Spares

Get A Quote

If you would like a quote for our standing frames please submit a request through our online form or contact us directly on the below details.



You may get a call back from us to discuss your requirements in more detail to be able to advise the correct equipment for your needs.
